NXP USA Inc. MMPF0100F9ANES
Specifications
NXP USA Inc. MMPF0100F9ANES technical specifications, attributes, parameters and parts with similar specifications to NXP USA Inc. MMPF0100F9ANES.
| Type | Parameter |
| Mounting Type | Surface Mount, Wettable Flank |
| Package / Case | 56-VFQFN Exposed Pad |
| Surface Mount | YES |
| Operating Temperature | -40°C~105°C TA |
| Packaging | Tray |
| Published | 2011 |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Number of Terminations | 56 |
| ECCN Code | EAR99 |
| Applications | Converter, i.MX6 |
| HTS Code | 8542.39.00.01 |
| Technology | MOS |
| Terminal Position | QUAD |
| Terminal Form | NO LEAD |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Number of Functions | 1 |
| Supply Voltage | 3.6V |
| Terminal Pitch | 0.5mm |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| JESD-30 Code | S-XQCC-N56 |
| Number of Outputs | 12 |
| Supply Voltage-Max (Vsup) | 4.5V |
| Supply Voltage-Min (Vsup) | 2.8V |
| Number of Channels | 14 |
| Analog IC - Other Type | POWER SUPPLY SUPPORT CIRCUIT |
| Voltage - Input | 2.8V~4.5V |
| Adjustable Threshold | YES |
| Voltage - Output | Multiple |
| Height Seated (Max) | 0.9mm |
| Length | 8mm |
| Width | 8mm |
| RoHS Status | ROHS3 Compliant |
MMPF0100F9ANES Description
MMPF0100F9ANES is a type of 14-channel configurable power management integrated circuit (PMIC) developed by NXP Semiconductors / Freescale. It is characterized by a highly programmable/ configurable architecture with fully integrated power devices and minimal external components. It is combined with up to six buck converters, six linear regulators, an RTC supply, and a coin-cell charger so that a complete system can be powered by it. Several pre-programmed standard versions are available based on its on-chip one-time programmable (OTP) memory.
MMPF0100F9ANES Features
Four to six buck converters, depending on configuration
Individually programmable ON, OFF, and standby modes
I2C control
Six general-purpose linear regulators
Programmable output voltage, sequence, and timing
MMPF0100F9ANES Applications
Tablets
IPTV
eReaders
Set-top boxes
Industrial control
Medical monitoring
Home automation/ alarm/ energy management
